AIRBUS A-319

Aircraft
Name:
A-319
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Low wing
Tail:
Regular tail, mid set
WTC
M
APC
C
Type Code:
L2J
Aerodrome Reference Code:
4C
RFF Category:
6
Engine:
Jet
Engine Count:
Multi
Position:
Underwing mounted
Landing gear:
Tricycle retractable
Manufacturered as
AIRBUS A-319
AIRBUS A-319 ACJ
AIRBUS ACJ
AIRBUS VC-1 ACJ

A319

Medium Range passenger jet manufactured by Airbus. The A319 is the shorter variant of the A320 family of aircraft.

A new "neo" (new engine option) series of the A320 family was developed since 2010 with first aircraft being delivered in 2016. The "neo" aircraft feature new engines (PW 1100G or CFM LEAP-1A) and a new type of wingtips, called "sharklets". The existing aircraft are referred to as "ceo" by Airbus, meaning "current engine option".

Note: While a "ceo" aircraft may or may not be equipped with sharklets, all "neo" aircraft are equipped with sharklets. The sharklet version features a 1.7m wider wingspan.

Technical Data
Wing span:
35.80 m
Length:
33.84 m
Height:
11.76 m
Powerplant:

2 x CFM56-5B (98kN) or
2 x IAE V2524-A5 (104.6kN) turbofans.

Engine Model:
CFM International CFM56, International Aero Engines V2500
Indicative Performance Data
Take-Off
V2:
135 kts
Distance:
1750 m
MTOW:
64000 kg
Initial Climb (to 5000 ft)
IAS:
165 kts
ROC:
2500 ft/min
Initial Climb (to FL150)
IAS:
290 kts
ROC:
2200
Initial Climb (to FL240)
IAS:
290 kts
ROC:
1500 ft/min
MACH Climb
MACH:
0.78
ROC:
1000 ft/min
Cruise
TAS:
450 kts
MACH:
0.79
Ceiling:
390
Range:
1800 NM
Initial Descent (to FL240)
MACH:
0.78
ROD:
1000 ft/min
Descent (to FL100)
IAS:
290 kts
ROD:
3500 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
210 kts
ROD:
n/a
Approach
Vapp (IAS):
130 kts
Distance:
1350 m

Accidents & Serious Incidents involving

Further Reading:
  • Airbus reference document which provide to airlines, MROs, airport planners and operators the general dimensions of the aircraft, as well as the necessary information for ramp, servicing operations or maintenance preparation: Airbus A319: Airplane characteristics for aiport planning AC, 01 May 2017
