AEROSTAR (1) 600

Aircraft
Name:
600
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Mid wing
Tail:
Regular tail, low set
WTC
L
APC
B
Type Code:
L2P
Engine:
Piston
Engine Count:
Multi
Position:
In wing mounted
Landing gear:
Tricycle retractable
Manufacturered as
AEROSTAR (1) 600
AEROSTAR (1) 601
AICSA Aerostar
MACHEN Superstar
PIPER Aerostar
PIPER PA-60 Aerostar
TED SMITH Aerostar

AEST

High performance light aircraft. In service since 1968. Developed as response to the AERO COMMANDERS twins. Exists in several versions, last more powerful and turbocharged model PA-60-700P. Built first by TED SMITH (later AEROSTAR) United States, transferred to PIPER as PA-60 Aerostar in 1982.

Technical Data
Wing span:
10.41 m
Length:
10.61 m
Height:
3.70 m
Powerplant:

600A: 2 x 290 HP Lycoming IO-540-K1J5 piston engines with 3 blade propellers.

Engine Model:
Lycoming O-540
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
472 m
MTOW:
2500 kg
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
1800 ft/min
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
220 kts
MACH:
n/a
Ceiling:
210
Range:
1200 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
n/a
ROD:
n/a
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
n/a
Distance:
317 m
