B06

BELL B-206 JetRanger

Aircraft
Name
B-206 JetRanger
Manufacturer
Body
Narrow
Wing
Rotary
Position
Two-blade main rotor
Tail
Two-blade tail rotor
Type Code
H1T
Engine
Turboshaft
Engine Count
Single
Position
Above cabin
Landing gear
Skids
Manufacturered as
PANHA 2061
COMMONWEALTH (1) BA-206 Kiowa
COMMONWEALTH (1) CA-32 Kiowa
COMMONWEALTH (1) Kiowa
BELL 406 Combat Scout
BELL 206L LongRanger
BELL 206B JetRanger
BELL 206A JetRanger
BELL JetRanger
BELL CH-136
BELL CH-139
BELL COH-58
BELL Combat Scout
BELL Creek
BELL TH-206
BELL TH-67 Creek
BELL 406
BELL SeaRanger
BELL Kiowa
BELL OH-58 Kiowa Warrior
BELL OH-58 Kiowa
BELL VH-4 JetRanger
BELL LongRanger
BELL Kiowa Warrior
BELL TH-57 SeaRanger
AGUSTA JetRanger
AGUSTA Hkp6 JetRanger
AGUSTA LongRanger
AGUSTA AB-206 LongRanger
AGUSTA AB-206 JetRanger

B06

The Bell 206 is a two-bladed, single-engine helicopter, manufactured by Bell Helicopter.

Technical Data
Wing span (metric)
10.16 m
Length (metric)
2.83 m
Height (metric)
12.11 m
Powerplant

1 x Allison 250-C20J turboshaft, 420 shp (310 kW).

Engine Model(s)
Allison 250
Indicative Performance Data
Take-Off
V2
n/a
Distance
n/a
MTOW
1451 kg
Initial Climb (to 5000 ft)
IAS
1350 kts
ROC
n/a
Initial Climb (to FL150)
IAS
n/a
ROC
n/a
Initial Climb (to FL240)
IAS
n/a
ROC
n/a
MACH Climb
MACH
n/a
ROC
n/a
Cruise
TAS
120 kts
MACH
n/a
Ceiling
135
Range
374 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
n/a
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
n/a
Distance
n/a
