BELL B-430

Aircraft
Name:
B-430
Manufacturer:
Wing:
Rotary
Position:
Four-blade main rotor
Tail:
Two-blade tail rotor
WTC
L
Type Code:
H2T
Engine:
Turboshaft
Engine Count:
Multi
Position:
Above cabin
Landing gear:
Skids or tricycle retractable
Manufacturered as
BELL 430

B430

The Bell 430 is a twin-engined light-medium helicopter built by Bell Helicopter Textron. It is a stretched and more powerful development of the Bell 230, which, in turn, was based on the earlier Bell 222.

Technical Data
Wing span:
12.80 m
Length:
13.44 m
Height:
3.73 m
Powerplant:

2 x Rolls-Royce 250-C40B 783 hp (584 kW).

Engine Model:
Rolls-Royce 250
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
n/a
MTOW:
4218 kg
Initial Climb (to 5000 ft)
IAS:
60 kts
ROC:
1400 ft/min
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
130 kts
MACH:
n/a
Ceiling:
146
Range:
324 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
130 kts
ROD:
1000 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
40 kts
Distance:
n/a
