B701

BOEING 707-100

Aircraft
Name
707-100
Manufacturer
Body
Narrow
Wing
Fixed Wing
Position
Low wing
Tail
Regular tail, mid set
WTC
M
APC
C
Type Code
L4J
RFF Category
7
Engine
Jet
Engine Count
Multi
Position
Underwing mounted
Landing gear
Tricycle retractable
Manufacturered as
BOEING 707-100

B701

Medium to long range airliner/freighter. In service since 1958. First member of BOEINGs 707 production serie. First models with turbojets, later re-engined with JT3D turbofans. C-137/CC-137 military freighter version. The B701 is member of the B707 family of aircraft.

Technical Data
Wing span (metric)
39.90 m
Length (metric)
44.07 m
Height (metric)
12.90 m
Powerplant

4 x P&W JT3D-1 (76.2 kN) turbofans.

Engine Model(s)
Pratt & Whitney JT3D
Indicative Performance Data
Take-Off
V2
n/a
Distance
n/a
MTOW
86184 kg
Initial Climb (to 5000 ft)
IAS
160 kts
ROC
1300 ft/min
Initial Climb (to FL150)
IAS
377 kts
ROC
1600
Initial Climb (to FL240)
IAS
377 kts
ROC
1400 ft/min
MACH Climb
MACH
0.81
ROC
800 ft/min
Cruise
TAS
470 kts
MACH
0.80
Ceiling
390
Range
3530 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
289 kts
ROD
1640 ft/min
Descent (FL100 & below)
IAS
n/a
MCS
240 kts
ROD
n/a
Approach
Vapp (IAS)
130 kts
Distance
n/a
