BOEING 777-200LR and 777-F

Aircraft
Name:
777-200LR and 777-F
Manufacturer:
Body:
Wide
Wing:
Fixed Wing
Position:
Low wing
Tail:
Regular tail (Dihedral)
WTC
H
APC
C
Type Code:
L2J
RFF Category:
9
Engine:
Jet
Engine Count:
Multi
Position:
Underwing mounted
Landing gear:
Tricycle retractable
Manufacturered as
BOEING 777-200LR
BOEING 777-F

B77L

The 777-200LR became the world's longest-range commercial airliner when it entered service in 2006. It has a maximum range of 9,395 nm and was intended for ultra-long-haul routes such as New York to Singapore, or Chicago to Sydney - up to about 19 hours flying time. The -200LR features an increased MTOW and the same wing as the 777-300ER. The 777F is a cargo version of this variant. Three optional auxiliary fuel tanks take the baseline fuel tank capacity from 181,289 l to 203,570 l. Other new features include raked wingtips, redesigned main landing gear, and additional structural strengthening. As with the -300ER, the -200LR is equipped with wingtip extensions of 3.90 m. B77L is member of the B777 family of aircraft.

Technical Data
Wing span:
60.90 m
Length:
63.70 m
Height:
18.60 m
Powerplant:

2 x GE 90-110B1 (489 kN) or
2 x GE 90-115BL (512 kN).

Engine Model:
General Electric GE90
Indicative Performance Data
Take-Off
V2:
123 kts
Distance:
2970 m
MTOW:
347450 kg
Initial Climb (to 5000 ft)
IAS:
175 kts
ROC:
2500 ft/min
Initial Climb (to FL150)
IAS:
280 kts
ROC:
2000
Initial Climb (to FL240)
IAS:
280 kts
ROC:
1500 ft/min
MACH Climb
MACH:
0.83
ROC:
2000 ft/min
Cruise
TAS:
490 kts
MACH:
0.84
Ceiling:
431
Range:
9380 NM
Initial Descent (to FL240)
MACH:
0.84
ROD:
1000 ft/min
Descent (to FL100)
IAS:
240 kts
ROD:
3000 ft/min
Descent (FL100 & below)
IAS:
210 kts
MCS:
240 kts
ROD:
2000 ft/min
Approach
Vapp (IAS):
140 kts
Distance:
1700 m
