BE36

BEECH 36 Bonanza (piston)

Aircraft
Name
36 Bonanza (piston)
Manufacturer
Body
Narrow
Wing
Fixed Wing
Position
Low wing
Tail
Regular tail, mid set
WTC
L
APC
A
Type Code
L1P
Engine
Piston
Engine Count
Single
Position
Nose mounted
Landing gear
Tricycle retractable
Manufacturered as
RAYTHEON Bonanza (36, piston)
RAYTHEON 36 Bonanza (piston)
HAWKER BEECHCRAFT Bonanza
HAWKER BEECHCRAFT 36 Bonanza
COLEMILL Starfire Bonanza 36
BEECH 36 Bonanza (piston)
BEECH Bonanza (36, piston)

BE36

High performance light aircraft. In service since 1968 (turbocharged since 1979). Stretched, more powerful development of BEECH 33 Debonair. More than 3700 BEECH A36 and 600 turbocharged BEECH 36TC were built by Beechcraft. Production continued by RAYTHEON.

Technical Data
Wing span (metric)
8.40 m
Length (metric)
8.10 m
Height (metric)
2.60 m
Powerplant

1 x 300 HP Continental IO-550-B piston or

Engine Model(s)
Continental IO-550
Continental O-520
Indicative Performance Data
Take-Off
V2
n/a
Distance
n/a
MTOW
1656 kg
Initial Climb (to 5000 ft)
IAS
n/a
ROC
1230 ft/min
Initial Climb (to FL150)
IAS
n/a
ROC
n/a
Initial Climb (to FL240)
IAS
n/a
ROC
n/a
MACH Climb
MACH
n/a
ROC
n/a
Cruise
TAS
176 kts
MACH
n/a
Ceiling
185
Range
221 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
n/a
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
n/a
Distance
n/a
