CASA C-212 Aviocar

Aircraft
Name:
C-212 Aviocar
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
WTC
M
APC
A
Type Code:
L2T
Engine:
Turboprop
Engine Count:
Multi
Manufacturered as
CASA Aviocar
CASA C-212 Aviocar
CASA C-41 Aviocar
CASA Tp89 Aviocar
DIRGANTARA Aviocar
DIRGANTARA NC-212 Aviocar
NURTANIO Aviocar
NURTANIO NC-212 Aviocar
NUSANTARA Aviocar
NUSANTARA NC-212 Aviocar

C212

Short Take-Off and Landing (STOL) utility transport, maritime patrol and ECM platform aircraft. In service since 1974. Exists in several civil and military versions: Aviocar for utility transport, Elint as ECM platform and Patrullero for maritime patrol. Primary designed for Spanish Air Force. Civil version: C-212C. Military version: C-212M. Production ceased in 1978. Re-introduced in 1979 with more powerful engines and strengthened landing gear as C-212-200. Third development was the C-212-300. Actual model: C212-400, more powerful and heavier with Electronic Flight Instrument System and improved main cabin. Licence production by IPTN, Indonesia.

Technical Data
Wing span:
20.30 m
Length:
16.20 m
Height:
6.60 m
Powerplant:

2 x 777 SHP Garrett TPE 331-5-251C or

Engine Model:
Garrett AiResearch TPE-331
Indicative Performance Data
Take-Off
V2:
100 kts
Distance:
900 m
MTOW:
7700 kg
Initial Climb (to 5000 ft)
IAS:
130 kts
ROC:
1000 ft/min
Initial Climb (to FL150)
IAS:
140 kts
ROC:
500
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
178 kts
MACH:
n/a
Ceiling:
270
Range:
1240 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
170 kts
ROD:
800 ft/min
Descent (FL100 & below)
IAS:
170 kts
MCS:
n/a
ROD:
800 ft/min
Approach
Vapp (IAS):
90 kts
Distance:
500 m
