LOCKHEED MARTIN C-130J Hercules

Aircraft
Name:
C-130J Hercules
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
High wing
Tail:
Regular tail, low set
WTC
M
APC
C
Type Code:
L4T
Engine:
Turboprop
Engine Count:
Multi
Position:
(Front) Wing leading mounted
Landing gear:
Tricycle retractable
Manufacturered as
LOCKHEED MARTIN C-130J Hercules
LOCKHEED MARTIN CC-130J Hercules
LOCKHEED MARTIN EC-130J Hercules
LOCKHEED MARTIN HC-130J Hercules
LOCKHEED MARTIN Hercules (AE-2100 engines)
LOCKHEED MARTIN KC-130J Hercules
LOCKHEED MARTIN WC-130J Hercules

C30J

Tactical and multi-role transporter. In service since 1998. New upgrade of C-130 with changes to the cockpit, now with Electronic Flight Instrument System displays and HUD (Head Up Display) and new engines (6 blade propeller). Stretched version C-130J-30 (since 1999) with the fuselage 4.6 meters longer than the original version (see C130J-30 data below). It offers a capability increase between 31 and 50% depending on the configuration. Different versions include: Psychological warface version EC-130J (since 1999), Tanker version KC-130J (since 2000) and weather reconnaissance version WC-130J (since 1999).

Technical Data
Wing span:
40.40 m
Length:
29.80 m
Height:
11.84 m
Powerplant:

4 x 4.591 SHP Allison 2100 D3 turboprops with 6 blade propellers.

Engine Model:
Rolls-Royce AE 2100
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
n/a
MTOW:
79300 kg
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
300 kts
MACH:
0.52
Ceiling:
310
Range:
2910 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
n/a
ROD:
n/a
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
n/a
Distance:
n/a
