FAIRCHILD DORNIER 328

Aircraft
Name:
328
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
High wing
Tail:
T-tail
WTC
M
APC
B
Type Code:
L2T
Engine:
Turboprop
Engine Count:
Multi
Position:
(Front) Wing leading mounted
Landing gear:
Tricycle retractable
Manufacturered as
DORNIER 328
FAIRCHILD DORNIER 328

D328

High speed, short range commuter airliner. In service since 1993. Turboprop regional airliner development in the 30 seat class. DORNIER 328 variants:

  • 328-100 initial standard production,
  • The 328-110 is heavier with greater range,
  • The 328-120/130 has an improved short field performance and the
  • 323-200 has an increased airspeed.
  • Jet powered derivative 328JET.
Technical Data
Wing span:
20.98 m
Length:
21.11 m
Height:
7.24 m
Powerplant:

2 x 1.815 SHP or 2 x 2.180 SHP take-off rated for short field P&W PW119A turboprops with 6 blade propellers.

Engine Model:
Pratt & Whitney Canada PW100
Indicative Performance Data
Take-Off
V2:
110 kts
Distance:
1000 m
MTOW:
13990 kg
Initial Climb (to 5000 ft)
IAS:
140 kts
ROC:
2000 ft/min
Initial Climb (to FL150)
IAS:
220 kts
ROC:
1500
Initial Climb (to FL240)
IAS:
220 kts
ROC:
1000 ft/min
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
310 kts
MACH:
0.54
Ceiling:
310
Range:
1000 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
1000 ft/min
Descent (to FL100)
IAS:
280 kts
ROD:
1500 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
160 kts
ROD:
n/a
Approach
Vapp (IAS):
110 kts
Distance:
1200 m
