DOUGLAS DC-8-50

Aircraft
Name:
DC-8-50
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Low wing
Tail:
Regular tail, mid set
WTC
H
APC
C
Type Code:
L4J
RFF Category:
7
Engine:
Jet
Engine Count:
Multi
Position:
Underwing mounted
Landing gear:
Tricycle retractable
Manufacturered as
DOUGLAS DC-8-50
DOUGLAS DC-8-50 Jet Trader
DOUGLAS Jet Trader
MCDONNELL DOUGLAS DC-8-50
MCDONNELL DOUGLAS DC-8-50 Jet Trader
MCDONNELL DOUGLAS Jet Trader

DC85

Long range airliner and freighter. In service since 1959. Built as DC-8- 10, 20, 30, 40 and 50. DC-8-10 initial domestic version, DC-8-20 with more powerful engines. Intercontinental series - 30, - 40 and - 50 with shorter fuselage and more powerful engines. Only DC-8-50 remain in service as freighter. The DC85 is member of the DC-8 family of aircraft.

Technical Data
Wing span:
43.40 m
Length:
45.90 m
Height:
12.90 m
Powerplant:

10: 4 x P&W JT3C-6 (60,5 kN) or
20: 4 x P&W JT4A-9 (75,3 kN) or
30, 40, 50: 4 x P&W JT3D-3 (80,6 kN) turbofans.

Engine Model:
Pratt & Whitney JT3C, Pratt & Whitney JT4A
Indicative Performance Data
Take-Off
V2:
130 kts
Distance:
3000 m
MTOW:
147400 kg
Initial Climb (to 5000 ft)
IAS:
160 kts
ROC:
1300 ft/min
Initial Climb (to FL150)
IAS:
290 kts
ROC:
1200
Initial Climb (to FL240)
IAS:
290 kts
ROC:
1000 ft/min
MACH Climb
MACH:
0.78
ROC:
800 ft/min
Cruise
TAS:
465 kts
MACH:
0.80
Ceiling:
360
Range:
4900 NM
Initial Descent (to FL240)
MACH:
0.78
ROD:
1000 ft/min
Descent (to FL100)
IAS:
290 kts
ROD:
2500 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
210 kts
ROD:
n/a
Approach
Vapp (IAS):
137 kts
Distance:
2000 m
