BOMBARDIER Dash 8 Q300

Aircraft
Name:
Dash 8 Q300
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
WTC
M
APC
B
Type Code:
L2T
Engine:
Turboprop
Engine Count:
Multi
Manufacturered as
DE HAVILLAND CANADA Dash 8 (300)
DE HAVILLAND CANADA DHC-8-300 Dash 8

DH8C

Short range turboprop commuter airliner. In service since 1989. Stretched development of DHC-8-200. Exists in three basic forms: standard 300, 300A/B with higher gross weights and 300E. Further stretched version DHC-8-400. From 1996 all Dash 8s delivered with a computer controlled noise and vibration suppression system. Type designation with a Q for quiet. DH8C is a member of the Bombardier Dash 8 Series.

Technical Data
Wing span:
27.43 m
Length:
25.68 m
Height:
7.49 m
Powerplant:

2 x 2.380 SHP PWC PW 123 turboprops with 4 blade propellers.

Engine Model:
Pratt & Whitney Canada PW100
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
1085 m
MTOW:
18600 kg
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
220 kts
MACH:
n/a
Ceiling:
270
Range:
1950 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
n/a
ROD:
n/a
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
n/a
Distance:
1177 m
