DE HAVILLAND CANADA DHC-7

Aircraft
Name:
DHC-7
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
High wing
Tail:
T-tail
WTC
M
APC
A
Type Code:
L4T
Engine:
Turboprop
Engine Count:
Multi
Position:
(Front) Wing leading mounted
Landing gear:
Tricycle retractable
Manufacturered as
DE HAVILLAND CANADA Dash 7
DE HAVILLAND CANADA DHC-7 Dash 7
DE HAVILLAND CANADA EO-5 Dash 7
DE HAVILLAND CANADA O-5 Dash 7
DE HAVILLAND CANADA RC-7 Dash 7

DHC7

Short Take-Off and Landing (STOL) turboprop airliner. In service since 1978. Designed as a STOL aircraft. The only major development of Dash 7 was the 150 series with higher take-off weight. The 151 was the equivalent freighter. Production ended in 1988 following Bombardiers take-over of the DE HAVILLAND CANADA. 111 Dash 7 were built, approx. 60 were in commercial service in 1999. RC-7B modified ex-airliner DHC-7 to airborne reconnaissance aircraft for US Army. Six aircraft will be delivered by 2003.

Technical Data
Wing span:
28.40 m
Length:
24.60 m
Height:
8.00 m
Powerplant:

4 x 1.120 SHP P&W PT6A-50 turboprops with 4 blade propellers.

Engine Model:
Pratt & Whitney Canada PT6
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
670 m
MTOW:
19900 kg
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
215 kts
MACH:
n/a
Ceiling:
240
Range:
1170 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
n/a
ROD:
n/a
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
n/a
Distance:
660 m
