EMBRAER Brasilia

Aircraft
Name:
Brasilia
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Low wing
Tail:
T-tail
WTC
M
APC
B
Type Code:
L2T
Engine:
Turboprop
Engine Count:
Multi
Position:
(Front) Wing leading mounted
Landing gear:
Tricycle retractable
Manufacturered as
EMBRAER Brasilia
EMBRAER EMB-120 Brasilia
EMBRAER VC-97 Brasilia
NEIVA Brasilia
NEIVA EMB-120 Brasilia

E120

Twin turboprop regional airliner. In service since 1985. Stretched and pressurized regional airliner development of the military EMB-121 Xingu. Exists in some versions:

  • EMB-120RT with reduced take-off weight,
  • EMB-120ER with extended range and many cargo versions.
  • VC-97 Brazil Air Force version for VIP transport and surveillance operation.
  • EMB-120ER: Length 20,07 m MTOW 11990kg.
Technical Data
Wing span:
19.77 m
Length:
19.63 m
Height:
6.05 m
Powerplant:

2 x 1.800 SHP PWC PW 118 turboprops with 4 blade propellers.

Engine Model:
Pratt & Whitney Canada PW100
Indicative Performance Data
Take-Off
V2:
120 kts
Distance:
1400 m
MTOW:
9072 kg
Initial Climb (to 5000 ft)
IAS:
150 kts
ROC:
2900 ft/min
Initial Climb (to FL150)
IAS:
220 kts
ROC:
1000
Initial Climb (to FL240)
IAS:
220 kts
ROC:
800 ft/min
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
290 kts
MACH:
0.45
Ceiling:
335
Range:
1400 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
290 kts
ROD:
1500 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
170 kts
ROD:
n/a
Approach
Vapp (IAS):
120 kts
Distance:
1400 m
