J328

FAIRCHILD DORNIER 328JET

Aircraft
Name
328JET
Manufacturer
Body
Narrow
Wing
Fixed Wing
Position
High wing
Tail
T-tail
WTC
M
APC
C
Type Code
L2J
Engine
Jet
Engine Count
Multi
Position
Underwing mounted
Landing gear
Tricycle retractable
Manufacturered as
RUAG Dornier 328 JET Envoy
FAIRCHILD DORNIER Envoy 3
FAIRCHILD DORNIER 328JET Envoy 3
FAIRCHILD DORNIER 328JET
AVCRAFT Dornier 328JET
328 SUPPORT SERVICES Dornier 328JET

J328

Regional airliner. In service since 1999. Regional jet airliner development in the 30 seat class. Based on the FAIRCHILD DORNIER 328 turboprop airliner. Corporate model Envoy 3. A 40 Seat version 428Jet was dropped from the development in 2000. Envoy 3: MTOW 14,900kg Range 2000 NM.

Technical Data
Wing span (metric)
20.90 m
Length (metric)
20.90 m
Height (metric)
7.20 m
Powerplant

2 x 26,9 kN P&W PW306B turbofans.

Indicative Performance Data
Take-Off
V2
n/a
Distance
1382 m
MTOW
15200 kg
Initial Climb (to 5000 ft)
IAS
n/a
ROC
n/a
Initial Climb (to FL150)
IAS
n/a
ROC
n/a
Initial Climb (to FL240)
IAS
n/a
ROC
n/a
MACH Climb
MACH
n/a
ROC
n/a
Cruise
TAS
400 kts
MACH
n/a
Ceiling
350
Range
1130 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
n/a
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
n/a
Distance
1306 m
