LOCKHEED TriStar

Aircraft
Name:
TriStar
Manufacturer:
Body:
Wide
Wing:
Fixed Wing
Position:
Low wing
Tail:
Regular tail, low set
WTC
H
APC
C
Type Code:
L3J
Engine:
Jet
Engine Count:
Multi
Position:
Underwing mounted and fin-integrated
Landing gear:
Tricycle retractable
Manufacturered as
LOCKHEED L-1011 TriStar
LOCKHEED TriStar

L101

Long range wide-body airliner. In service since 1972 (L1011-500 since 1979). Lockheed's second and last wide-body airliner development. Built in the standard fuselage models:

  • 1/100/200, with different powerful engines and the short fuselage version L1011-500.
  • L1011-250 combines fuselage of 200 with powerplant of 500. Production ceased in 1983.
  • KC-1 and C-2 strategic tanker and freighter conversions of L1011-500 for Royal Air Force.

Specs:

  • L1011-200: MTOW 211,375kg.
  • L1011-500: MTOW 231,300kg Wing span 50,1 m Length 50,8 m.
Technical Data
Wing span:
47.40 m
Length:
54.30 m
Height:
16.90 m
Powerplant:

Variants:

Engine Model:
Rolls-Royce RB211
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
2426 m
MTOW:
211375 kg
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
2800 ft/min
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
480 kts
MACH:
n/a
Ceiling:
420
Range:
4360 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
n/a
ROD:
n/a
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
n/a
Distance:
1734 m
