GATES LEARJET Learjet 31

Aircraft
Name:
Learjet 31
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Low wing (winglets)
Tail:
T-tail
WTC
M
APC
B
Type Code:
L2J
Engine:
Jet
Engine Count:
Multi
Position:
Both sides of rear fuselage
Landing gear:
Tricycle retractable
Manufacturered as
GATES LEARJET 31
LEARJET 31

LJ31

Light turbofan corporate jet. In service since 1988. Improved development of Learjet 35/36, combined fuselage and powerplant of Learjet 35/36 with modern wings of Learjet 55/60 (deltafins below the T-tail). Models 31A/ER for extended range with higher take-off weight. Gates Learjet is now part of the Bombardier Canada Group.

Technical Data
Wing span:
13.50 m
Length:
14.80 m
Height:
3.80 m
Powerplant:

2 x 15.6 kN Garrett TFE731-2B turbofans.

Engine Model:
Garrett TFE731
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
1158 m
MTOW:
8028 kg
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
5100 ft/min
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
463 kts
MACH:
0.81
Ceiling:
510
Range:
1882 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
n/a
Descent (to FL100)
IAS:
n/a
ROD:
n/a
Descent (FL100 & below)
IAS:
131 kts
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
131 kts
Distance:
874 m
