LNC4

LANCAIR Lancair 4

Aircraft
Name
Lancair 4
Manufacturer
Body
Narrow
Wing
Fixed Wing
Position
Low wing
Tail
Regular tail, mid set
WTC
L
APC
A
Type Code
L1P
Engine
Piston
Engine Count
Single
Position
Nose mounted
Landing gear
Tricycle retractable
Manufacturered as
PAI Lancair 4
PADC Lancair 4
NEICO Lancair 4
LANCAIR Lancair 4

LNC4

The Lancair IV and IV-P are a family of four-seat low-wing retractable-gear composite monoplanes powered by a 550 cubic inch Continental turbo-normalised piston engine. Lancair IV-P is the pressurized version.

Technical Data
Wing span (metric)
10.82 m
Length (metric)
7.62 m
Height (metric)
2.40 m
Powerplant

1 x Continental TSIO-550 six cylinder, horizontally opposed piston engine, 350 hp.

Engine Model(s)
Continental IO-550
Indicative Performance Data
Take-Off
V2
n/a
Distance
550 m
MTOW
1400 kg
Initial Climb (to 5000 ft)
IAS
n/a
ROC
n/a
Initial Climb (to FL150)
IAS
n/a
ROC
n/a
Initial Climb (to FL240)
IAS
n/a
ROC
n/a
MACH Climb
MACH
n/a
ROC
n/a
Cruise
TAS
291 kts
MACH
n/a
Ceiling
290
Range
1350 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
n/a
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
n/a
Distance
490 m
