MCDONNELL DOUGLAS MD-90

Aircraft
Name:
MD-90
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Low wing
Tail:
T-tail
WTC
M
APC
C
Type Code:
L2J
Engine:
Jet
Engine Count:
Multi
Position:
Both sides of rear fuselage
Landing gear:
Tricycle retractable
Manufacturered as
BOEING MD-90
MCDONNELL DOUGLAS MD-90
SHANGHAI MD-90

MD90

Short to medium range airliner. In service since 1994. More powerful, stretched development of DC-9 family. Models:

  • MD-90-30 standard version,
  • MD-90-30T licence production by TRUNKLINERS, China, and
  • MD-90-55 optimized for extended range.

Short fuselage development MD-95, renamed by BOEING to 717-200. MD-90-55: MTOW 78,245kg.

Technical Data
Wing span:
32.90 m
Length:
46.50 m
Height:
9.30 m
Powerplant:

Variants:

Engine Model:
International Aero Engines V2500
Indicative Performance Data
Take-Off
V2:
140 kts
Distance:
2200 m
MTOW:
78245 kg
Initial Climb (to 5000 ft)
IAS:
170 kts
ROC:
3200 ft/min
Initial Climb (to FL150)
IAS:
290 kts
ROC:
2500
Initial Climb (to FL240)
IAS:
290 kts
ROC:
2500 ft/min
MACH Climb
MACH:
0.74
ROC:
1000 ft/min
Cruise
TAS:
440 kts
MACH:
0.76
Ceiling:
370
Range:
2200 NM
Initial Descent (to FL240)
MACH:
0.76
ROD:
1000 ft/min
Descent (to FL100)
IAS:
290 kts
ROD:
3500 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
210 kts
ROD:
n/a
Approach
Vapp (IAS):
138 kts
Distance:
1600 m
