AERO SPACELINES 377SGT Super Guppy

Aircraft
Name:
377SGT Super Guppy
Manufacturer:
Body:
Wide
Wing:
Fixed Wing
WTC
M
Type Code:
L4T
Engine:
Turboprop
Engine Count:
Multi
Manufacturered as
AERO SPACELINES 377SGT Super Guppy
AERO SPACELINES Super Guppy

SGUP

The Aero Spacelines Super Guppy is a large, wide-bodied cargo aircraft that is used for hauling outsized cargo components. It was the successor to the Pregnant Guppy, the first of the Guppy aircraft produced by Aero Spacelines. Five were built in two variants, both of which were colloquially referred to as the Super Guppy.

  • Aero Spacelines B-377-SG Super Guppy – Prototype of a much enlarged version of the guppy using C-97J components, powered by four Pratt & Whitney T-34-P-7WA turbo-prop engines.
  • Aero-Spacelines B-377-SGT Super Guppy Turbine (Guppy 201) – Production version powered by Allison 501-D22C turbo-prop engines, using an enlarged cargo section built from scratch instead of being converted from original C-97J components.
Technical Data
Wing span:
47.63 m
Length:
43.84 m
Height:
14.78 m
Powerplant:

4 x Allison 501-D22C turboprops, 3,491 kW each

Engine Model:
Allison T56
Indicative Performance Data
Take-Off
V2:
n/a
Distance:
n/a
MTOW:
n/a
Initial Climb (to 5000 ft)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL150)
IAS:
n/a
ROC:
n/a
Initial Climb (to FL240)
IAS:
n/a
ROC:
n/a
MACH Climb
MACH:
n/a
ROC:
n/a
Cruise
TAS:
220 kts
MACH:
n/a
Ceiling:
250
Range:
2540 NM
Initial Descent (to FL240)
MACH:
n/a
ROD:
1000 ft/min
Descent (to FL100)
IAS:
240 kts
ROD:
1430 ft/min
Descent (FL100 & below)
IAS:
270 kts
MCS:
n/a
ROD:
1500 ft/min
Approach
Vapp (IAS):
n/a
Distance:
n/a
