CESSNA 318A/B/C

Aircraft
Name:
318A/B/C
Manufacturer:
Body:
Narrow
Wing:
Fixed Wing
Position:
Low wing
Tail:
Cruciform tail
WTC
L
APC
B
Type Code:
L2J
Engine:
Jet
Engine Count:
Multi
Position:
In wing mounted
Landing gear:
Tricycle retractable
Manufacturered as
CESSNA 318A
CESSNA 318B
CESSNA 318C
CESSNA T-37

T37

Basic and advanced trainer. In service since 1957. Basic trainer development for the US Air Force. Built in a few versions: T-37A initial version (534 aircraft were built) replaced by more powerful T-37B in 1959 (449 aircraft were built) optional with wing-tip tanks. Final version T-37C Tweet or Tweeti Bird for export (269 aircraft were built). The US Air Force T-37 will be replaced by the PC-9 based T-6A Texan 2. The T-37 is the standard trainer of several Air Forces. Germany Air Force in USA, NATO, Greece, Turkey, Pakistan and Korea being the major users.

Technical Data
Wing span:
10.30 m
Length:
8.90 m
Height:
2.80 m
Powerplant:

2 x Continental/Teledyne J69-T-25 (4,56 kN) turbojets.

Engine Model:
Teledyne CAE J69
Indicative Performance Data
Take-Off
V2:
90 kts
Distance:
650 m
MTOW:
2980 kg
Initial Climb (to 5000 ft)
IAS:
120 kts
ROC:
3300 ft/min
Initial Climb (to FL150)
IAS:
280 kts
ROC:
2000
Initial Climb (to FL240)
IAS:
280 kts
ROC:
2000 ft/min
MACH Climb
MACH:
0.60
ROC:
1000 ft/min
Cruise
TAS:
400 kts
MACH:
0.65
Ceiling:
390
Range:
800 NM
Initial Descent (to FL240)
MACH:
0.65
ROD:
5000 ft/min
Descent (to FL100)
IAS:
300 kts
ROD:
5000 ft/min
Descent (FL100 & below)
IAS:
n/a
MCS:
n/a
ROD:
n/a
Approach
Vapp (IAS):
95 kts
Distance:
700 m
