TIGR

AIRBUS HELICOPTERS EC-665

Aircraft
Name
EC-665
Manufacturer
Wing
Rotary
Position
Four-blade main rotor
Tail
Three-blade tail rotor
WTC
L
Type Code
H2T
Engine
Turboshaft
Engine Count
Multi
Position
Both sides of fuselage
Landing gear
Tricycle fixed
Manufacturered as
EUROCOPTER EC-665 Tiger
EUROCOPTER EC-665 Tigre
EUROCOPTER Tiger
EUROCOPTER Tigre
AUSTRALIAN AEROSPACE Tiger
AUSTRALIAN AEROSPACE EC-665 Tiger

TIGR

The Eurocopter Tiger (company designation EC 665) is an attack helicopter manufactured by Eurocopter. In Germany it is known as the Tiger; in France and Spain it is called the Tigre.

Technical Data
Wing span (metric)
13.00 m
Length (metric)
14.80 m
Height (metric)
3.83 m
Powerplant

2 x Rolls-Royce/Turboméca/MTU MTR390 turboshafts, 873 kW (1,170 shp) each.

Engine Model(s)
MTR390
Indicative Performance Data
Take-Off
V2
n/a
Distance
n/a
MTOW
6100 kg
Initial Climb (to 5000 ft)
IAS
n/a
ROC
2200 ft/min
Initial Climb (to FL150)
IAS
n/a
ROC
n/a
Initial Climb (to FL240)
IAS
n/a
ROC
n/a
MACH Climb
MACH
n/a
ROC
n/a
Cruise
TAS
124 kts
MACH
n/a
Ceiling
110
Range
690 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
n/a
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
n/a
Distance
n/a
